CE70H3DP

Description

Shaft diameter 70 mm, sturdy and heavy machine body, with rigid parts for bending even profiles with high sections, on request available with lateral guide system.

MODELS AVAILABLE

CE70H3DP – Hydraulic 3drive rolls bouble pinch – Three phase
CE70H3DPNC2 – Hydraulic 3drive rolls variable speed 4 inverter double pinch – Three phase
CE70H3DPCNC3 – Hydraulic 3drive rolls and side pressure rolls – Three phase

FEATURES

Shafts diameter 70 mm
High repeatability
Spheroidal cast iron structure
Possibility of mouthing the material from both sides
High-strength alloy steel shafts with threading to allow micrometric adjustment of the rollers
Upon request stiffening support for central roller
Symmetrical and asymmetrical bending due to independent shaft movement
Independent movement of the lower roller axes reduces machining waste (reduced straight sections)
Touch screen control with USB storage capability
Low voltage remote control and dead man joystick device
Universal tool set included

One of the most powerful CNC controls in its class (mod. CE70H3DPCNC3)

10” touch screen with high definition graphics, with all the performance
and sophisticated algorithms in a high level and easy to use CNC, to
make the most of the machine’s potential
10” colour touch screen display (1024 x 600 pixel resolution)
128 MB silicon disk
2D graphic display
2 RS232 serial port
1 CAN port with 9-pin SUBD f connector
1 Ethernet port 10/100 Mbit (LAN connection)
1 VGA port for external monitor connection
2 USB ports (2.0)
